CTP Capacitive Touch Screen Panel

You can rest assured to buy CTP Capacitive Touch Screen Panel from our factory. To develop these different technologies, we have invested heavily in IP development and currently have more than 100 patents, of which 60% are for performance improvement and 40% are related to process development.

With the widespread use of capacitive touch technology on smartphones, people are becoming more and more familiar and accustomed to its unique natural and intuitive characteristics. This has also affected many other non-consumer products, leading to innovative changes in human-machine interfaces. For example, multi-touch has the functions of single-finger click, switch, scroll, gesture functions such as double-finger zoom and rotate, single-finger gestures and multi-touch.

Applications include other industries such as industrial control, medical, home automation, equipment and automobiles.

RGB has advanced capacitive technology that supports multi-touch, ensuring a responsive and intuitive user experience. If you need the display to work even when wearing thick gloves, or need waterproofing, we can meet your needs.

Capacitive touch screens are the basic interface that enables users to intuitively interact with advanced and innovative devices, helping to seamlessly complete complex applications.

RGB is recognized as a pioneer touch solution provider, providing a comprehensive range of customizable touch screen options to meet the stringent requirements of professional and reliable designs.

Our CTP Capacitive Touch Screen Panels are seamlessly integrated into a wide array of intelligent electronic devices, encompassing cutting-edge consumer and commercial products, dependable automotive and medical equipment, as well as robust industrial and outdoor applications.

Specifications :

10.1" Projected Capacitive Touch Panel Module

1.    Structure: GG

      (Tempered Cover Glass + Double-Side ITO Sensor Glass);

2.    Touch Controller: GT928; 10 points Multi-Touch;

3.    Interface: I2C; Address 0xBA/0xBB; Interrupt Pull Low;

4.    Firmware version: A1;

5.    Resolution: 1280x800;

6.    Light transmittance: ≥ 88%;

7.    Operation temperature: -20°C ~ +70°C;

8.    Storage temperature: -30°C ~ +80°C;

9.    Operation voltage: DC 3.3V(VDD); 3.3V(I/O);

10.  Insulation resistance: 20MΩ (DC 25V);

11.  RoHS compliant.
